Basic Info.
Model NO.
Carbon Steel Ball
Size Range
1mm-180mm Bicycle Steel Ball
Grade
G40-1000 Bicycle Steel Ball
Hardness
60 Min. HRC (Surface-Hardend)
Material Mark
AISI1010/ AISI1015/ C15/ 1.0413/ JIS Swrm 12/ En32
International Equivalent
1010, S10c, DC01, 1.0330, C10c, 1.0214
Shape
Solid Round Bearing Steel Ball
Certifications
BV; ISO; ASTM
Model No.
AISI1010 Low Carbon Steel Ball
Application
Low Quality Bearing, Oiler, Roller, Sliding
Magnetic
Yes
Transport Package
Box, Plastic Bag, Carton, Pallet
Specification
45mm carbon steel ball
Trademark
SUHUA
Origin
Jiangsu, Changzhou
HS Code
8482910000
Production Capacity
300ton/Month
Product Description
ISO, BV 45mm big metal sphere carbon steel balls
Introduction:
1. Casehardened surface balls and low hardness core.
2. Good characteristics of superficial hardness, low resistance to corrosive attack, magnetic.
Detailed information:
Production process:
Packaging:
Type 1: Plastic bag + box + carton + wooden pallet
Type 2: Plastic bag + carton + wooden pallet
Type 3: Our package: export cartons, steel drums, wooden pallets
About us:
1. Established since year 1986, more than 27 years experience and specialized in steel balls manufacturer and ball related products.
2. High precision instruments and technical staffs.
3. Offer the good quality service and product with short delivery times.
Services:
1. All the inquiries will be reply within 24 hours
2. For the steel ball, please kindly let us know the size, material, grade and quantity.
3. For the bearing, please kindly let us know bearing type, material, Accuracy Grade/Class, and quantity.
FAQ:
Q1: What kind of ball can supplied by Huari?
A: Stainless steel ball, Chrome steel ball, Carbon steel ball, Brass ball, Aluminum ball, Copper ball, coated ball.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF.
Q4: How many days for delivery?
A: Inventory with 1-3 days or 25-30 days. The specific delivery time depends on your quantity.
Contact us:
Site: czhuari.en.made-in-china.com
Any futher query, please do contact us anytime.
Introduction:
1. Casehardened surface balls and low hardness core.
2. Good characteristics of superficial hardness, low resistance to corrosive attack, magnetic.
Detailed information:
| Low Carbon Steel Ball AISI1010 | ||||||||||||
| 1. Material | AISI1010/AISI1015/C15/1.0413/JIS SWRM 12/EM32 ASTM A/29 | |||||||||||
| 2. Size Range | 1mm-180mm | |||||||||||
| 3. Grade | G40-1000 | |||||||||||
| 4. Hardness | 60min. HRC(Surface-hardened) | |||||||||||
| 5. Characteristic | (a)Casehardened surface balls and low hardness core (b)Superficial hardness (c)Low resistance to corrosive attack | |||||||||||
| 6. Magnetic | Yes | |||||||||||
| 7. Application | Low quality bearing, oiler, roller, sliding block.... | |||||||||||
| 8. Chemical composition | ||||||||||||
| C% | Si% | Mn% | Cr% | Ni% | Mo% | P% | S% | AI% | Cu% | |||
| min. | 0.12 | --- | 0.30 | --- | --- | --- | --- | --- | --- | --- | ||
| max. | 0.17 | 0.30 | 0.60 | 0.02 | 0.25 | 0.05 | 0.035 | 0.035 | 0.01 | 0.30 | ||
| 9.Packing | Standard: 10kg or 20kg per carton, 1 ton per pallet or as customer required | |||||||||||
| 10.Conditioning | dry or oiled | |||||||||||
| 11.Delivery time | Stock within a short time or 35 days. | |||||||||||
| CHANGZHOU HUARI STEEL BALL CO., LTD. | ||||||||||||
Production process:
| Manufacture process of steel balls | ||||
| Step 1 Heading | Balls blanks are cold headed from rolls of wire. | |||
| Step 2 Flashing | Rolling balls between two hard alloy plates to removes the slight band and small protrusions. | |||
| Step 3 Heat treat | Heating balls to a high temperature in furnace and quenching balls in a liquid bath. | |||
| Step 4 Rough grind | Rolling balls between the face of a fixed iron plate and a very hard fire-grit grinding wheel. Then rolled the hardened ground balls between two cast iron plates. | |||
| Step 5 Cleaning | The final production operation cleans the finished balls and adds a shiny luster. | |||
| Step 6 Final Inspection | Balls are gauged, visually inspected and subjected to other quality tests to insure every customer's specifications are achieved. | |||
| Step 7 Packaging | The balls are packaged in accordance with customer specifications for shipping. | |||
Packaging:
Type 1: Plastic bag + box + carton + wooden pallet
Type 2: Plastic bag + carton + wooden pallet
Type 3: Our package: export cartons, steel drums, wooden pallets
About us:
1. Established since year 1986, more than 27 years experience and specialized in steel balls manufacturer and ball related products.
2. High precision instruments and technical staffs.
3. Offer the good quality service and product with short delivery times.
Services:
1. All the inquiries will be reply within 24 hours
2. For the steel ball, please kindly let us know the size, material, grade and quantity.
3. For the bearing, please kindly let us know bearing type, material, Accuracy Grade/Class, and quantity.
FAQ:
Q1: What kind of ball can supplied by Huari?
A: Stainless steel ball, Chrome steel ball, Carbon steel ball, Brass ball, Aluminum ball, Copper ball, coated ball.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF.
Q4: How many days for delivery?
A: Inventory with 1-3 days or 25-30 days. The specific delivery time depends on your quantity.
Contact us:
Site: czhuari.en.made-in-china.com
Any futher query, please do contact us anytime.
