Basic Info.
Model NO.
1.0mm to 140mm
Customized
Non-Customized
Raw Material
Aluminium/Zircominium Oxide
Samples
Available
Grade Range
G10 -100
Delivery
20 Days
Transport Package
Carton - Woodencase
Specification
1.0mm -100mm
Origin
China
Production Capacity
500, 000PCS/Week
Product Description
Qingdao Fuqin Imp. & Exp. Co., Ltd. is a professional manufacturing and exporting company, mainly supplying balls, rollers, rod ends and so on. The team's is professional and aims to sport qualified products, quick service and quick delivery.
We have worked for the automotive, bearing,and cosmetics industry for more than 15 years. To reach the aim we are continuously developing...
| Material | Material Model | Material Grade | Color | Main Mateiral Characteriestics |
| Si3N4 | JSN-W4C(HIP) | Class I (ASTM F2094) | Black | High fatigue life, high reliability, high strength, high temperature resistance, wear resistance, non-magnetic |
| JSN-W4(HIP) | Gray | Corrosion resistance, high strength, non-magnetic | ||
| JSN-05W(HIP) | Class II (ASTM F2094) | Black | High fatigue life, high temperature resistance, wear resistance, high strength | |
| JSN-12 | Black | High temperature resistance, high strength, wear resistance | ||
| JSN-63 | Gray | High temperature resistance, high strength, wear resistance | ||
| Al2O3 | AO-3N01 | 99.7wt% | Yellow | High hardness, high temperature resistance |
| AO-4N01 | 99.99wt% | White | Corrosion resistance, high hardness, high temperature resistance | |
| SiC | SC-HD01 | Black | High hardness and corrosion resistance | |
| ZrO2 | ZO-HD01 | High strength, high toughness, corrosion resistance | ||
| YSZ | ZO-HD01 | White | High strength, high toughness, corrosion resistance |
| Material | Dia (mm) | Highest Grade Level | Process Characteristic |
| Si3N4 | 0.4~140 | G5 | GPS,HIP |
| Al2O3 | ≥1.0 | G10 | |
| SiC | 0.8~19.05 | G16 | |
| ZrO2 | ≥0.1 | G10 | |
| YSZ |
High precision / speed bearings,
High / low temperature bearings/volves,
Hybrid bearings
Non-magnetic bearings,
Hiprecision linear motion system,
Robot arm joint ,
Automotive,
High / low temperature bearings/volves,
Hybrid bearings
Non-magnetic bearings,
Hiprecision linear motion system,
Robot arm joint ,
Automotive,
1. Quality control by the professional team
2. Quick respond to your inquiry and other questions
3. Quick delivery
